Applications:

Non-clogging submersible sewage pumps , oil-filled motor , forinstallation in small lift stations , drainage systems or raw waterapplications .Made specially for:Homes and farms Mobile home parks and motelsSchools and hospitalsMunicipal package systemsIndustrial treatment systemsDewatering applications

Specifications

1. Power Cable: Standard cord is 10m

2. Liquid Temperature: 104°F(40℃) continuous

3. Motor: B insulation class, IP68 protection

4. Single Phase: Built in thermal protector

5. Accessories: Float switch is available
Part Specifications

1. O-ring: Buna-N

2. Motor Housing: GG20

3. Shaft: AISI 420

4. Double-sided Mechanical Seal: Buna-N elastomers
     Motor side: Carbon VS Silicon Carbide
     Pump side: Silicon Carbide VS Silicon Carbide

5. Impeller:GG20

6. Pump Casing: GG20
